| Input | 4X4-20mA |
| Output | COM |
| Power | 20-30DC |
| Input Description | Four configurable 4-20mA input channels with four discrete (contact closure) input channels |
| Output Description | Redundant (Dual) MODBUS RTU (RS-485) communication links and One Ethernet (MODBUS/TCP) communication link |
| Power Description | 20-30DC |
| Housing Description | Universal DIN-style housing mounts on G-type and Top Hat DIN-rails |
| Input Type | 4-20mA Only |
| Communication Protocol | MODBUS RTU, MODBUS/TCP, OPC, Web Server |
| Device Power | 24VDC |
| Physical Layer | Ethernet, RS-485, Shielded Twisted Pair |
| Network Type | Peer to Host (I/O directly connected to host system) |
| Math or Logic Capability | Yes |
| Housing/Enclosure | DIN Rail Enclosure |
| RoHS Compliant | Yes |
| Data Sheet |
|
Not Applicable
| Manual |
|
| Network Addressing Configuration (NAC) Client Software required for configuring the MNCS |
|
| NCSConfig PC Configuration Software |
|
Not Applicable
